LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
75
7.37. Transmit CGMS/TSCH Indicate Register [B]
Transmit CGMS/TSCH indicate register [B] indicates CGMS information and identification of TS type for source packet input from port B
at TSP IC I/F.
AD R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
82h R CGMSB-2 TSCHB-2 CGMSB-1 TSCHB-1
Initial Value “00 b” “00 h” “00 b” “00 h”
BIT Bit Name Action Value Function
15 - 14 CGMSB-2 Read -
Indicates CGMS information for source packet indicated in TSCHB-2 (bit13 to 8).
(MSB: bit15, LSB: bit14)
13 - 8 TSCHB-2 Read -
Indicates if ID of TS type for source packet input from port B at TSP IC I/F is
different from that in low bit (TSCHB-1).
(MSB: bit13, LSB: bit8)
7 - 6 CGMSB-1 Read -
Indicates CGMS information for source packet indicated in TSCHB-1 (bit5 to 0).
(MSB: bit7, LSB: bit6)
5 - 0 TSCHB-1 Read -
Indicates ID of TS type for source packet input first from port B at TSP IC I/F
(MSB: bit5, LSB: bit0)
