LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
67
BIT Bit Name Action Value Function
0 Indicates that CIP header of received Isochronous packet is normal.
1 Rx CIP err-B Read
1
Indicates that CIP header of received Isochronous packet has an error.
Cleared to ‘0’ by lead of this register.
0
Indicates that FMT range of CIP header of received Isochronous packet is the value
allowed to be received at DV-EN, DSS- EN or TS-EN (1Ch –bit10 to 8)
(DV=‘00000’, MPEG2=‘10000’ or DSS=‘100001’).
0 Rx FMT err-B Read
1
Indicates that FMT range of CIP header of received Isochronous packet is other
than the value allowed to be received at DV-EN, DSS-EN or TS- EN (1Ch – bit10 to
8) (DV=‘00000’, MPEG2=‘10000’ or DSS=‘100001 ’).
Clears to ‘0’ by reading of this register.
