LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
19
Chapter 6 Internal Register
This chapter explains the MB86617A internal register.
Note that the access of internal register is applied only 16 bits access.
WRITE READ
Address
(HEX)
Register Name Register Name
00 mode-control mode-control
02 (reserved) flag & status
04 Instruction-fetch Instruction-fetch
06 Interrupt-mask setting [A] Interrupt indicate [A]
08 Interrupt-mask setting [B] Interrupt indicate [B]
0A (reserved) Receive Acknowledge
0C A-buffer data port transmit A-buffer data port receive
0E (reserved) (reserved)
10 TSP transmit information setting [A] TSP transmit information setting [A]
12 TSP transmit information setting [B] TSP transmit information setting [B]
14 transmit offset setting [A] (upper) transmit offset setting [A] (upper)
16 transmit offset setting [A] (lower) transmit offset setting [A] (lower)
18 transmit offset setting [B] (upper) transmit offset setting [B] (upper)
1A transmit offset setting [B] (lower) transmit offset setting [B] (lower)
1C TSP receive information setting TSP receive information setting
1E
transmit DSS packet header setting [A]
(most significant)
receive DSS packet header setting [A]
(most significant)
