LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
71
7.33. PHY/LINK Register/Address Setting Register
PHY/LINK register/address setting register is the register that sets address in order to access PHY/LINK register indirectly. PHY/LINK
register indicated with address set by this register can be accessed from PHY/LINK register/access port.
AD R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
60h R/W - - - - - - - - - phy/link-addr
Initial Value ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ “00 h”
BIT Bit Name Action Value Function
Read - Always indicate ‘0’.
15 - 7 reserved
Write - Always write in ‘0’.
6 - 0 phy/link-addr
Read/
Write
-
Set address of PHY/LINK register to be accessed.
(MSB: 6, LSB: 0)
