BIT Bit Name Action Value Function
0
Selects CGMS information input from TSP -IC as EMI information to be output to
CP-IC.
4 EMI select-A
Read/
Write
1
Selects setting value of set EMI-A (bit3 to 2) as EMI information to be output to
CP-IC.
3 - 2 set EMI-A
Read/
Write
-
Set EMI information to be output to CP-IC.
Valid only when EMI select -A (bit4) is ‘1’.
(MSB: bit3, LSB: bit2)
0
Does not insert internal 27 MHz counter value to System clock count ran ge of DSS
packet header.
1 27M count-A
Read/
Write
1
Inserts internal 27 MHz counter value to System clock count range of DSS packet
header.
0
Does not mask port A input of TSP-IC interface.
Read in input data from port A at transmit.
0 port mask -A
Read/
Write
1
Masks port A input of TSP -IC interface.
Does not read in input data from port A at transmit.
