LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
93
8.11. Physical register #10 (read)
Physical Register#10 is the register that indicates Compliance_level of this node.
phy/
link-
addr
R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
1E h R - - - - - - - - Compliance_level
Fixed value ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ “01 h”
Description of Each Bit
BIT Bit Name Action Value Function
15 - 8 reserved Read - Always indicate ‘0’.
7 - 0
Compliance_l
evel
Read -
Indicate that this node supports P1394a standard.
(MSB: 7 , LSB: 0)
Always indicate fixe value “01 h”.
