LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
77
BIT Bit Name Action Value Function
0
Indicates that the packet indicated in CGMSA-1 and TSCHA-1 (80h - bit7 to 0) was
finally input from port A at TSP IC I/F.
Read
1
Indicates that the packet indicated in CGMSA-2 and TSCHA-2 (80h - bit15 to 8)
was finally input from port A at TSP IC I/F.
2 act -TSCHA
Write - Clears to ‘0’ by writing “1”.
0
Indicates that the value indicated in CGMSA-2 and TSCHA-2 (80h - bit15 to 8) is
invalid.
Read
1
Indicates that the value indicated in CGMSA-2 and TSCHA-2 (80h - bit15 to 8) is
valid. 1 vld-TSCHA-2
Write - Clears to ‘0’ by writing “1”.
0
Indicates that the value indicated in CGMSA-1 and TSCHA-1 (80h -bit7 to 0) is
invalid.
Read
1
Indicates that the value indicated in CGMSA-1 and TSCHA-1 (80h -bit7 to 0) is
valid.
0 vld-TSCHA-1
Write - Clears to ‘0’ by writing “1”.
