7.26. Receive Isochronous Packet Header Indicate Register 4 [B]
Receive Isochronous packet header indicate register 4 [B] is the register that indicates Isochronous packet CIP header information received
by bridge-Bch.
AD R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
4Ah R - - - - Rx FMT -B
Rx
56-B
Rx STYPE-B
Initial value ‘0’ ‘0’ ‘0’ ‘0’ “3F” ‘0’ “00 h”
BIT Bit Name Action Value Function
15 - 12 reserved Read - Always indicate ‘0’.
11 - 6 Rx FMT -B Read -
Indicate FMT range of receive Isochronous packet CIP header.
(MSB: bit11, LSB: bit6)
5 Rx 56-B Read -
Indicates 50/60 range of receive Isochronous packet CIP header when receiving
DV.
Indicates TSF range of receive Isochronous packet CIP header when receiving
MPEG2-TS or DSS.
4 - 0 Rx STYPE-B Read -
Indicate STYPE range of CIP header of receive Isochronous packet.
(MSB: bit4, LSB: bit0)
