LSI S pecification

MB86617A

Rev.1.0

Fujitsu VLSI

47

BIT

Bit Name

Active

Value

Function

9~8

reserved

Read

-

Always indicate ‘0’.

0

Indicates that CGMS information input from port A of TSP IC I/F is not changed.

7

CG chg-A

Read

1

Indicates that CGMS information input from port A of TSP IC I/F is changed.
Clears to ‘0’ by lead of this register.

0

Indicates that TS classification ID input from port A of TSP IC I/F is not changed.

6

TS chg-A

Read

1

Indicates that TSCH classification ID input from port B of TSP IC I/F is not
consistent with TSCH classification ID (10h- bit12 to 7 set TS-ID- A or 12h- bit12 to
7 set TS-ID-B) to be stored to FIFO.
Clears to ‘0’ by lead of this register.

0

Indicates that synchronization byte of received MPEG2-TS input from CP -IC by
bridge-Bch is 47h

5

no 47h-A

Read

1

Indicates that synchronization byte of received MPEG2 -TS input from CP -IC by
bridge-Bch is not 47h
Clears to ‘0’ by lead of this register.

0

Indicates that FIFO on TSP IC I/F side of bridge-Ach is not full.

4

TSP FIFO

full-A

Read

1

Indicates that FIFO on TSP IC I/F side of bridge-Ach is full.

0

Indicates that FIFO on TSP IC I/F side of bridge-Ach is not empty.

3

TSP FIFO

emp-A

Read

1

Indicates that FIFO on TSP IC I/F side of bridge-Ach is empty.

0

Indicates transmit data length input from TSP IC I/F is normal.

2

T x-length-err -

A

Read

1

Indicates transmit data length input from TSP IC I/F is not consistent with
specified format data length.
Deletes transmit data without writing into FIFO.
Clears to ‘0’ by lead of this register.

1 - 0

reserved

Read

-

Always indicate ‘0’.
