FUJITSU MB86617A User Manual
Page 137
LSI S pecification
MB86617A
Rev.1.0
Fujitsu VLSI
132
12.2
Recommended Connection for Cable Power Supply
The example of recommended connection of cable power supply for 1394 cable is shown below.
Figure 12.2
Recommended connection for cable power supply
510K
Ω
±
5%
91K
Ω
±
5%
CPS
Cable
Power
(max 33V)
2.2uF
