LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
42
BIT Bit Name Action Value Function
0
Deletes received data and reports FMT error when MPEG2 -TS data is received.
ISO packet header and CIP header are indicated in register.
8 T S-EN
Read/
Write
1 Allows receiving MPEG2 -TS data.
0 Does not output the packet received by bridge-Ach to port B of TSP-IC I/F.
7 TV2A
Read/
Write
1 Outputs the packet received by bridge-Ach to port B of TSP -IC I/F.
0 Does not output the packet received by bridge-Ach to port A of TSP-IC I/F.
6 TV1A
Read/
Write
1 Outputs the packet received by bridge-Ach to port A of TSP -IC I/F.
Read - Always indicates ‘0’.
5 - 4 reserved
Write - Always write in ‘0’.
0
Outputs DSS packet with DSS packet header received by bridge- Bch to TSP-IC in
unit of 140 byte.
3
output DSS
size-
Read/
Write
1
Outputs DSS packet without DSS packet header received by bridge-Ach to TSP -IC
in unit of 130 byte.
Removed DSS packet header is stored at receive DSS packet header indicate register
[A].
0 Outputs received data to TSP -IC in synchronization with 6.144 MHz TSCLK.
2 TCLKSL
Read/
Write
1 Outputs received data to TSP -IC in synchronization with 3.072 MHz TSCLK.
0 Outputs to port A when TSCMP (bit0) is ‘1’.
1 CMPSEL
Read/
Write
1 Outputs to port B when TSCMP (bit0) is ‘1’.
0 Does not merge packet received by Ach and Bch.
0 TSCMP
Read/
Write
1 Outputs to one TSP-IC after merging packets received by Ach and Bch.
Note 1) Do not set TV2B (bit15), TV1B (bit14), and DV1B (bit12) to ‘1’ simultaneously.
Note 2) Do not set TV2A (bit7), TV1A (bit6), and DV1A (bit4) to ‘1’ simultaneously.
Note 3) Do not set TV2B (bit15) and TV2A (bit7) to ‘1’ simultaneously.
Note 4) Do not set TV1B (bit14) and TV1A (bit6) to ‘1’ simultaneously.
Note 5) Do not set ‘1’ to TV2B (bit15), TV1B (bit14), TV2A (bit7) and TV1A(bit6) when TSCMP (bit0) is set to ‘1’.
Note 6) FMT error is reported when receiving data format other than DV-EN (bit10), DSS -EN (bit9) and TS-EN (bit8) regardless of
their settings.
