LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
79
BIT Bit Name Action Value Function
6 - 5 IPH EMI-A
Read/
Write
-
Set EMI information which are set in IPH of empty packet transmitted from
bridge-Ach.
Valid only when IPH select-A (bit7) is set to ‘1’.
(MSB: bit6, LSB: bit5)
EMI information after transmitting valid data depends on the setting of EMI
select-A (10h-bit4).
4 IPH OE-A
Read/
Write
-
Set Odd/Even value which is set in IPH of empty packet transmitted from
bridge-Ach.
Valid only when IPH select-A (bit7) is set to ‘1’.
EMI information after transmitting valid data depends on the setting of o/e select-A
(3Eh-bit8).
Read - Always indicate ‘0’.
3 - 0 reserved
Write - Always write in ‘0’.
