LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
127
(Note)Register and bit necessary for transmitting are as follows.
Data
Address
MPEG-TS DSS
00h TSPSB=0, CPSB=0
14h,16h Set value of transmit Offset(Ach).
18h,1Ah Set value of transmit Offset (Bch)
34h DBSA=06h, FNA=3h DBSA=09h, FNA=2h
36h TXFMTA=20h, TXCHA(Iso channel No.) TXFMTA=21h, TXCHA(Iso channel No.)
38h DBSB=06h, FNB=3h DBSB=09h, FNB=2h
3Ah TXFMTB=20h, TXCHB(Iso channel No.) TXFMTB=21h, TXCHB(Iso channel No.)
40h Set criteria for Late packet (Ach).
42h Set criteria for Late packet (Bch).
10h
Set at Ach transmitting.
TXSTA=1, TFA
Set at Ach transmitting.
TXSTA=1, TFA, TXFMTA=1,
IDSIZEA=1(DSS130)
12h
Set at Bch transmitting.
TXSTB=1, TFB
Set at Bch transmitting.
TXSTB=1, TFB, TXFMTB=1,
IDSIZEB=1(DSS130)
