FUJITSU MB86617A User Manual
Page 139
LSI S pecification
MB86617A
Rev.1.0
Fujitsu VLSI
134
12.4.
Configuration of Feedback Circuit at Crystal Oscillator
The example of
configuration of feedback circuit at crystal oscillator is shown below.
No outside resistance is needed because the feedback resistance is built -in.???
Figure 12.4
Configuration of feedback circuit at crystal oscillator
XO
XI
20pF
20pF
