LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
72
7.34. PHY/LINK Register Access Port
PHY/LINK register access port is the port to access PHY/LINK register indirectly. PHY/LINK register indicated with address set by
PHY/LINK register/address setting register can be accessed from this port.
AD R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
62h R/W phy/link-data
Initial Value “0000 h”
BIT Bit Name Action Value Function
Read -
Indicates PHY/LINK register contents defined by address set by PHY/LINK
register/address setting register. (MSB: 15, LSB: 0)
15 - 0 phy/link-data
Write -
Executes write in the process of register defined by this address set by PHY/LINK
register/address setting register. (MSB: 15, LSB: 0)
