LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
69
7.31. Cycle-timer-monitor Indicate Register
Cycle-timer-monitor indicate register indicates value of integrated cycle-timer register.
AD R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
5Ah R cycle-timer-monitor ( hi)
5Ch R cycle-timer-monitor ( lo)
Initial Value “0000 h”
BIT Bit Name Action Value Function
15 - 0
cycle-timer-m
onitor
Read -
Indicate value of built-in cycle-timer register.
(MSB: bit15, LSB: bit0)
Note) This register latches the lower word (5 A h) by reading out lower word (5Ch), and releases latch by reading out upper word.
To read out this register, make sure to read out in the order of 5C h
→
5A h, two as a set.
