LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
70
7.32. Ping Time Monitor Register
Ping time monitor register is the register that indicates time period of transmitting request packet to receiving response packet to the request.
AD R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
5Eh R Ping time monitor
Initial Value “0000 h ”
BIT Bit Name Action Value Function
15 - 0
Ping time
monitor
Read -
Indicate time period from transmitting request packet to receiving response packet
to the request. Counts by 20ns unit.
(MSB: bit15, LSB: bit0)
