Page 94
94
Operating Manual
BX400
S1
Hot-plug components
©
c
o
gni
ta
s.
Ge
se
lls
ch
ft f
ür T
ec
hn
ik
-Do
ku
m
ent
at
io
n
m
b
H 20
12
P
fa
d:
C
:\P
rogr
am
m
e
\F
CT
\t
im
_ap
p\
tim
_l
oc
al
\w
ork
\W
A
LT
E
R
\O
B
J_
DO
K
U
-9
24
9-0
04
.fm
1
ID indicator (blue)
Lit:
ID LED was activated via the management blade
Dark:
Normal operation
2
Status indicator (green/orange)
Lights up green: Power is supplied to the connection blade
Lights up
orange:
Switch error
Dark:
Power is not supplied to the connection blade
A
1-Gbit Ethernet ports for SFP modules for connection of fiber-optic or copper
cables (each with two integrated status LEDs)
3 (ERR) Error indicator (orange)
Dark:
No SFP transceiver error
Lit:
SFP transceiver error
Flashes:
SFP module not supported
4 (LINK) LAN connection indicator (green)
Lit:
LAN connection available
Flashes:
LAN connection active
Dark:
LAN connection unavailable or deactivated
B
1-Gbit Ethernet ports (RJ45 with two integrated LAN status LEDs each)
5
LAN transfer rate (green/orange)
Lights up
orange:
LAN transfer rate 1 Gbit/s
Lights up green: LAN transfer rate 100 Mbit/s
Dark:
LAN transfer rate 10 Mbit/s
6
LAN connection indicator (green)
Lit:
LAN connection available
Flashes:
LAN connection active
Dark:
LAN connection unavailable or deactivated
