BX400 S1

Operating Manual

117

Hot-plug components

8.2.11 Connection Blade Infiniband Switch 56 Gb 18/18

FDR

The Connection Blade Infiniband Switch 56 Gb 18/18 FDR provides the
following connections:

– 18 internal 56-Gbit Infiniband ports to the server blades
– 18 external 58-Gbit Infiniband connections through QSFP modules

This connection blade can be used in slots CB 3/4 see

figure "Connection blade

slots" on page 120

. It only supports server blades that are fitted with a 56 Gb

Infiniband mezzanine card (PY IB CX3 Mezz Card 56Gb 2 Port). For more
information, see the operating manuals for the relevant server blades.
