BX400 S1
Operating Manual
111
Hot-plug components
1
Status indicators for external Ethernet ports (green/orange)
Dark:
No signal carrier
Lights up green:
Link is established and port is active. Online is normal, but no
port activity.
Flickers green:
Port online, data transport
Flashes green:
–
Slow: Port online, but segmented
–
Fast: Internal loop
Lights up orange:
Port with no sync (light or signal carrier issue)
Flashes orange:
Slow (~ 2 sec. interval): Port deactivated.
Fast (~ 0.5 sec. interval): Port defective
2
Status indicators for external FC ports (green/orange)
Dark:
No signal carrier
Lit green:
Link is established and port is active. Online is normal, but no
port activity.
Flickers green:
Port online, data transport
Flashes green:
–
Slow: Port online, but segmented
–
Fast: Internal loop
Lights up orange:
Port with no sync (light or signal carrier issue)
Flashes orange:
Slow (~ 2 sec. interval): Port deactivated.
Fast (~ 0.5 sec. interval): Port defective
3
ID
ID indicator (blue)
Lit:
ID indicator was activated via the management blade
4
Health indicator (green/orange)
Dark:
Connection blade is powered off or power has failed
Lights up green:
Connection blade is running
Flashes orange
Connection blade has failed
5
Status indicator (green/orange)
Dark:
Connection blade is shut down and powered off normally
Lights up green:
Connection blade is running
Flashes green
Boot phase; connection blade is running diagnostics and
initialization programs
Flashes orange:
Warning: Critical failures have occured (e.g. The temperature
has risen the normal thermal threshold. The switch continues
operating.)
Lights up orange:
Warning: Fatal failures have occured. (Serious problem
detected; the switch is powered off.)
