BX400 S1 Operating Manual 59
5 Installation and operation
V
CAUTION!
Follow the safety instructions in the chapter "Important notes" on
page 31 .
5.1 Control and display elements
5.1.1 Front of system
The BX400 S1 system unit has an option for a fold-out ServerView Local
Service Display for Blade on the front. It is controlled by the management blade
and is used for local diagnostics and administration of the blade server. It is also
used for the initial configuration of the management blades, see
"Configuring
management blades" on page 72 .
Figure 10: ServerView Local Service Display for Blade (rack version)
The most important control and display elements can also be found on the front
of the ServerView Local Service Display for Blade. This means they are also
available when it is folded away.
I
The control and display elements of the server blades and storage
blades are described in the relevant operating manuals.
