56 Operating Manual BX400 S1
Installing the hardware
©
c
o gni
ta
s.
Ge
se
lls
ch
ft f
ür T
ec
hn
ik
-Do
ku
m
ent
at
io
n m
b H 20
12
P
fa
d:
C
:\P
rogr
am
m
e \F
CT
\t im
_ap
p\
tim
_l
oc
al
\w
ork
\W
A
LT
E
R
\O
B
J_
DO
K U
-9
24
5-0
04
.fm
Installation requirements for AC redundant configurations
The AC redundant configuration is with two PSUs plugged into a main AC
source and two other PSUs plugged into a separate AC source (e.g. UPS).
Installation requirements for non AC redundant configurations
For systems not requiring AC redundancy, the power supply can be installed
with up to 4 PSUs. The PSUs can be connected to a single or multiple AC
sources.
PSU configuration Max. DC loading DC redundancy
2 + 1 4800 W Yes
2 + 2 6400 W Yes
Table 2: Maximum DC loading requirements
PSU configuration Max. DC loading DC redundancy
2 3200 W No
2 + 1 4800 W Yes
2 + 2 6400 W Yes
Table 3: Maximum DC loading requirements
