FUJITSU PRIMERGY BX400 S1 - Manual (Page 109)

BX400 S1 Operating Manual 109
Hot-plug components
Port assignment
Each of the 8 server blades of a BX400 S1 system unit can be equipped with 2
FC mezzanine cards each with 2 ports (0, 1). Each of the server blade FC ports
is connected to a dedicated port of an FC pass thru connection blade in a
defined connection blade slot. The table below shows the port assignment of
mezzanine card ports and connection blade slots.
The FC pass thru port numbers are related to the server blade slot numbers.
Example
Mezzanine card 1 port 0 of server blade in slot 6 is connected to port 6 of FC
pass thru connection blade in slot 2 (CB2).
Port 0 of mezzanine card 1 is connected to port 7 of FC pass thru connection
blade in slot 3.
For information about port assignment of mezzanine cards and connection
blade slots please refer also to
"Fitting rules for connection blades" on page 120
and "Port assignment of the connection blades" on page 123
Mezzanine card 1 Mezzanine card 2
Server blade slot Port 0 Port 1 Port 0 Port 1
1 CB2 port 1 CB2 port 9 CB3 port 1 CB4 port 1
2 CB2 port 2 CB2 port 10 CB3 port 2 CB4 port 2
3 CB2 port 3 CB2 port 11 CB3 port 3 CB4 port 3
4 CB2 port 4 CB2 port 12 CB3 port 4 CB4 port 4
5 CB2 port 5 CB2 port 13 CB3 port 5 CB4 port 5
6 CB2 port 6 CB2 port 14 CB3 port 6 CB4 port 6
7 CB2 port 7 CB2 port 15 CB3 port 7 CB4 port 7
8 CB2 port 8 CB2 port 16 CB3 port 8 CB4 port 8
