BX400 S1
Operating Manual
47
Installing the hardware
Please observe the safety information and notes on rack mounting in
chapter
Fujitsu rack systems
The rack systems from Fujitsu support the installation of PRIMERGY servers:
– PRIMECENTER rack
– PRIMECENTER M1 rack
– DataCenter rack
– 19-inch standard rack (for the Japanese market)
– 19-inch slimline rack (for the Japanese market)
I
For information on mounting the system unit in the rack please refer to
the mounting instructions provided in this section. Further information
you find in the manual of your rack system.
For the Japanese market, please refer also to the "Rack system structure
guide.
I
Online documentation for rack installation can be found on:
http://manuals.ts.fujitsu.com/index.php?id=5406-5605-5606
(for the EMEA market)
http://jp.fujitsu.com/platform/server/primergy/manual/peri_rack.html
(for the Japanese market).
To accommodate the ventilation concept and ensure proper ventilation, any
unused areas in the rack must be sealed using dummy covers.
The power is supplied via the multiple socket outlets fitted in the rack (for the
EMEA market).
The main features of Fujitsu rack systems are as follows:
– support systems having a linear alignment feature to ensure that they can
be adjusted to different rack depths
Asymmetrical PRIMECENTER Rack and DataCenter Rack provide an
enhanced cable management in the lateral rack area.
3rd party racks
I
Installation in most current rack systems from other manufacturers
(3rd party racks) is also supported. For details please contact your sales
representative.
