Hot-plug components
V
CAUTION!
●
The downlink ports of connection blades DCB SW 10Gb and FEX
B22F 10Gb (Cisco) operate only at 10 Gb link speed.
●
The two connection blades within a fabric must have the same
technology, i.e. either Ethernet, Fibre Channel, SAS or Infiniband.
When filling the slots in fabrics 2 and 3, also make sure the server blades are
fitted with the appropriate mezzanine cards. The following rules apply for fitting
the mezzanine card slots of the server blades:
●
If a 1 Gb Ethernet mezzanine card is installed in slot 1 of a server blade, at
least one 1 Gb Ethernet connection blade must be installed in CB slot 2 of
the system unit.
●
If a 10 Gb Ethernet mezzanine card or 10Gb CNA mezzanine card is
installed in slot 1 of a server blade, at least one 10Gb Ethernet connection
blade, DCB SW 10 Gb 18/6+6 connection blade or FEX B22F 10Gb (Cisco)
connection blade must be installed in CB slot 2 of the system unit.
●
If an FC mezzanine card is installed in slot 1, at least one FC connection
blade must be installed in CB slot 2.
●
If a 1 Gb Ethernet mezzanine card is installed in slot 2 of a server blade, at
least one 1 Gb Ethernet connection blade must be installed in CB slot 3 or
in CB slot 4 of the system unit.
●
If a 10 Gb Ethernet mezzanine card or 10Gb CNA mezzanine card is
installed in slot 2 of a server blade, at least one 10Gb Ethernet connection
blade, DCB SW 10Gb 18/6+6 connection blade or FEX B22F 10Gb (Cisco)
connection blade must be installed in CB slot 3 or in CB slot 4 of the system
unit.
●
If an FC mezzanine card is installed in slot 2, at least one FC connection
blade must be installed in CB slot 3 or in CB slot 4.
●
If an Infiniband mezzanine card is installed in slot 2, an Infiniband connection
blade should be installed in CB slots 3 and 4.
I
In this case, both channels of the Infiniband mezzanine card are
used.
●
If a SAS mezzanine card is installed in slot 2, at least one SAS connection
blade must be installed in CB slot 3 or in CB slot 4.
