BX400 S1 Operating Manual 19
Introduction
10 Gb Ethernet / DCB connection blades
Connection Blade DCB SW 10Gb 18/6+6
18 internal 10-Gbit/s ports to the server blades
6 external 10-Gbit/s Data Center Bridging (DCB) capable ports through
Brocade branded SFP+ modules or SFP+ Twinax cables
6 external FC ports through 8-Gb SFP+ modules or 4-Gb SFP modules
Installable in all connection blade slots
I
The connection blade DCB SW 10Gb 18/6+6 in slots CB2
(fabric 2) and CB3/4 (fabric 3) only supports server blades that
are fitted with one of the following mezzanine cards:
– 10 Gbit CNA mezzanine card (MC-CNA102E)
– 10 Gbit CNA mezzanine card (MC-CNA112E)
– 10 Gbit Ethernet mezzanine card
Connection Blade FEX B22F 10Gb (Cisco)
16 internal 10-Gbit/s ports to the server blades
8 external 10-Gbit/s Ethernet ports for connection to the parent Cisco
Nexus 5000 Series Switch through Cisco branded copper Twinax
cables, Fabric Extender Transceivers (FET), or other standard 10
Gigabit Ethernet optics such as 10Gbase-SR, 10Gbase-LR, and
10Gbase-ER
Installable in all connection blade slots
I
The connection blade FEX B22F 10Gb (Cisco) in slots CB2
(fabric 2) and CB3/4 (fabric 3) only supports server blades that
are fitted with one of the following mezzanine cards:
– 10 Gbit CNA mezzanine card (MC-CNA112E)
– 10 Gbit Ethernet mezzanine card
