54 Operating Manual BX400 S1
Installing the hardware
©
c
o gni
ta
s.
Ge
se
lls
ch
ft f
ür T
ec
hn
ik
-Do
ku
m
ent
at
io
n m
b H 20
12
P
fa
d:
C
:\P
rogr
am
m
e \F
CT
\t im
_ap
p\
tim
_l
oc
al
\w
ork
\W
A
LT
E
R
\O
B
J_
DO
K U
-9
24
5-0
04
.fm
It is recommended to operate the management blade user interface in a
separate broadcast domain for the server management.
Ê
Connect the data cables according to the system configuration you require.
Connectors on the front of the system unit
Figure 8: Connectors for external devices on the Front-Side I/O Module (FSIOM)
For information on the front side connectors of the server blades for local
administration, see the operating manuals for the relevant server blades.
1 USB connectors to connect external devices to the server blades,
controlled by the management blade
2 Serial connector for a local management console
3 LAN connector for blade server management (including server blades
and connection blades)
/
