BX400 S1

Operating Manual

Installation and operation

5.1.2.3

Indicators on the hot-plug fan modules

Figure 17: Indicators on the hot-plug fan module

Power indicator (two-color)
Flashes green when the system unit is switched off but still
connected to the mains (standby mode).
Lights up green when the system unit is switched on and the fan
module is working properly.
Lights up yellow when a prospective error has been detected in the
fan module but the latter is still active.
