102 operating manual, Hot-plug components, Bx400 s1 – FUJITSU PRIMERGY BX400 S1 User Manual
Page 102
102
Operating Manual
BX400
S1
Hot-plug components
©
c
o
gni
ta
s.
Ge
se
lls
ch
ft f
ür T
ec
hn
ik
-Do
ku
m
ent
at
io
n
m
b
H 20
12
P
fa
d:
C
:\P
rogr
am
m
e
\F
CT
\t
im
_ap
p\
tim
_l
oc
al
\w
ork
\W
A
LT
E
R
\O
B
J_
DO
K
U
-9
24
9-0
04
.fm
1
Status indicator (green/orange)
Lit green:
Power is supplied to the connection blade
Flashes
alternately
green/orange:
Connection blade error
Dark:
Power is not supplied to the connection blade
2
Stack indicator (green/yellow) (future use)
Lit yellow:
Operating as a stack master
Flashes yellow:
Operating failure as a stack master
Lit green:
Operating as a stack slave
Flashes green
Operating failure as a stack slave or during master
election process
Dark:
No stacking
3
ID indicator (blue)
Lit:
ID LED was activated via the management blade
Dark:
Normal operation
6
Reset button
A
10-Gbit Ethernet ports for SFP+ modules for connection of fiber-optic cables or
for active twinax copper cables (each with two integrated status LEDs)
4 (ERR) Error indicator (orange)
Dark:
No SFP+ module error or SFP+ module not installed
Lit:
SFP+ module error
Flashes:
SFP+ module not supported
5 (LINK) LAN connection indicator (green)
Lit:
LAN connection available
Flashes:
LAN connection active
Dark:
LAN connection unavailable or deactivated
