PAPER HANDLING
User's Manual 3-4
ADJUSTING FOR PAPER
THICKNESS The printer can handle paper of different thicknesses, including
multipart forms with up to five parts (original plus four copies). For
details on paper thickness specifications, see Appendix B.
The paper thickness lever, located at the top right corner of the printer,
allows you to adjust for different paper thicknesses. Be sure to adjust
the paper thickness lever whenever you change the number of copies
being printed.
The paper thickness lever has nine settings: 1 to 5 and A to D . Use
Table 3.2 to determine the appropriate setting for your paper; then,
move the paper thickness lever to the appropriate position.
Adjusting the paper thickness lever
Paper thickness lever
Move to D.
