Setup Mode
USING SETUP MODE
User's Manual
5-49
Procedure
To print hex dumps, make sure that continuous forms paper is loaded
into the printer. Then proceed as follows:
1. Enter setup mode.
Press the FONT button and the MENU button simultaneously
until the printer beeps. Wait for the printer to stop printing
and check that the following <
printed:
<
SAVE&END MENU1 MENU2 HARDWRE ADJUST CONFIG DEFAULT LIST SELF-TST HEX-DUMP
V-ALMNT
2. Select the HEX-DUMP function.
Repeatedly press the LOCK button to position the red cursor
under HEX-DUMP, then press the FONT button or the MENU
button to select the HEX-DUMP function. The printer goes
online and prints a header and a short help menu.
3. Print the hex dump.
To start hex dump printing, send your file or program to the
printer. The printer goes online and prints the hex dump.
Press the FONT button or the MENU button to pause during
hex dump printing. To resume hex dump printing, press the
button again.
NOTE
When hex dump printing stops, the printer remains online in
setup mode (the ONLINE indicator is green). To print
another hex dump, send another file to the printer.
