FUJITSU DL3800 - Manual (Page 178)

PRINTER AND PAPER SPECIFICATIONS
B-6
User's Manual
PAPER SPECIFICATIONS Print Area
This section illustrates the recommended print area for single sheets
and continuous forms.
Print area for single sheets
May be
decreased to
4.23 mm
(1/6 inch).
However, line
spacing may be
uneven.
May be decreased
to 8.5 mm
(1/3 inch).
However, line
spacing may be
uneven.
Print area may be
off the paper,
depending on
paper setting or
width.
25.4 mm (1 inch)
25.4 mm (1 inch)
Print area
5.08 mm or more
(0.2 inch or more)
H H
H H
102-266.7 mm (4-10.5 in)
for 80-column printer
102–420 mm (4–16.5 in)
for 136-column printer
76-364 mm (3-14.3 in)
for 80-column printer
76–420 mm (3–16.5 in)
for 136-column printer
5.08–32 mm (0.2–1.26 in)
for 80-column printer
5.08-38 mm (0.2-1.5 in)
for 136-column printer
#B Appendix B 2000.09.20, 2:51 PM 6
