SETTING UP
2-10 User's Manual
GETTING ACQUAINTED
WITH YOUR PRINTER
Power switch
Paper
select
lever
Print head
Print guide
Front cover
Paper guide
Cut sheet
stand
Paper
thickness
lever
Platen knob
Platen
Interface connector Control panel
Now that your printer is assembled, take a moment to become familiar
with its major parts.
Looking at the printer from the front right side, you can see the parts of
the printer shown in the figure below.
Printer components (front and right)
The printer control panel has the buttons and indicators used to load
and feed paper (see Chapter 3) and select print features (see Chapter
4). The control panel also allows you to change the printer’s optional
settings (see Chapter 5).
