178 The T-1 Notebook : Reference & Guide
8.12 FX Track as a MIDI Keyboard
The pitch menu becomes a MIDI keyboard from within FX tracks allowing
live play of any connected instrument or device. Incoming MDI chords and
notes received will also show ORANGE
⬛ in the Pitch menu.
▌ FX TRACK AS A MIDI KEYBOARD CONTROLLER
1. Select or create an FX Track to edit. Press [VBx] where ‘x’ is the value
button for the track to select. An FX Track is lit MAGENTA ⬛ .
2. Turn (CHANNEL) to assign a MIDI out channel.
3. Select the Pitch Menu. Double tap (PITCH) or Double tap [VBx] for the
FX track to lock the value button display as the note keyboard layout
4. Playing notes and chords will be transmitted to MIDI out. Both incoming
MIDI and Manually played notes show as ORANGE ⬛ .
5. The scale and root can be edited if required.
Chromatic
D#
E A D G C
G# C# F#
F B
A#
MIDI FX Track Keyboard Example
MIDI OUT
FX Track
Pitch menu operates as a live playback
controller, similar to a MIDI Keyboard.
NOTES
MIDI & WiFi Connectivity
8
