Step 3: Press the Select Key
Press the
key to begin programming. The Select
LED flashes and the LCD display appears as shown below:
Step 4: Select Fixture Number
Press the Address keys corresponding to all fixture numbers
you wish to program. You can do the following:
•
Press one Address key to program a single fixture.
•
Press and hold two Address keys at the same time to
select a range of fixtures. For example, holding down
Address keys
<1>
and
<4>
at the same time selects fixture
numbers 1 through 4.
•
Press multiple Address keys, one at a time, to select
multiple fixtures. For example, pressing the
<2>
,
<7>
and
<5>
keys to program fixture numbers 2, 7 and 5 (the order
is not important).
Note
Selecting multiple fixture numbers means all fixtures
will share the same constructs and values. However,
random (unsynchronized) constructs will still play
back randomly. See the section titled “Programming
Hints” on page 3-2 for more information.
Step 5: Edit Constructs
Press one of the Construct keys to edit that construct. By
default, with no constructs programmed, the gate (shutter) is
closed so no light is emitted. Opening the shutter without
changing any other constructs projects a white beam at
maximum brightness. As you edit constructs, you will see
first-hand what your page looks like.
For detailed descriptions of all constructs, see the section
titled “Using the Construct Keys” on page 3-8.
