4-24 Preset Playback Studio Color LCD Controller
Things to Remember
• To change to another preset at any time, switch to the
bank containing the preset and press the corresponding
Preset key.
• If a preset is playing back a loop, you can quit playback
by pressing the
key until the Auto LED turns
OFF. The currently-running preset stops at the page that
is active when you press the
key.
• The way that master intensity and sequencing (auto
advance, audio 1 advance, audio 2 advance) are
implemented depends on your choice for dependent/
independent presets as described in “Switch B-6:
Dependent/Independent Presets” on page 2-7.
• The following settings can be manually overridden
during preset playback (see Chapter 6 for more
information):
Random playback, Audio1 (audio playback), Audio2
(audio playback), Auto playback, Color modulate,
Intensity (dim) modulate
PRESET
ADDRESS
