7-32 Crossloading Studio Color LCD Controller
Consult Appendix C for a complete selection of cabling and
connector wiring diagrams.
Crossload Procedure
The source controller is the one you want to transfer data
from; the destination controller is the one you want to
transfer data to.
1. Toggle the keys on each controller until their
Standby LEDs come ON.
2. Press and hold the key on the source controller
(about 10 seconds) until its LCD display shows the
following:
3. Press and hold the key on the destination controller
(about 10 seconds) until its LCD display shows the
following:
4. Press the key on the source controller to start the
transfer. While the transfer is taking place, the LCD display
on the destination controller appears similar to the one shown
below:
Note Press the key on each controller (in any order) at any time to stop the transfer. No data
corruption will result; stopping the transfer only limits D)
;$2$
-
;77()<
/)(;$2$
;()!D<;0:DD)
;$2$
