Studio Color LCD Controller
Remote Preset Access
6-19
6
Using Twelve-Level Preset Access
Twelve-level preset access allows you to record and play
back up to 96 presets (12 sets or levels of eight presets each).
Recording in Twelve-Level Preset Access
1.
Toggle the
/key on the Studio Color LCD
controller until the Preset LED comes ON.
2.
Press the Page
and
arrow keys on the Studio
Color LCD controller to select the page that you want to
record as a preset. If you want to record a loop as a preset,
select any page within the loop.
3.
This step applies to loops only. Press the
key. The
pages start advancing, playing back the loop.
4.
Press the
key. The Select LED flashes.
5.
Enable the analog controller channel corresponding to the
level you wish to use. (The signal that you use can be
momentary or latching.)
6.
For example, for level 1 (the first 8 presets), enable channel 1
on the analog controller. For level 2 (the second set of 8
presets, 9 to 16), enable channel 2 on the analog controller,
etc.
0V = Disabled
5V-10V = Enabled
7.
Use the Cursor
and
arrow keys to set the
controller for preset bank 1 as shown below:
8.
Press the Preset key (1 through 8) on the front panel on the
Studio Color LCD controller where you want to store the
preset. Adjust the settings for auto advance (page 4-18),
