5-4 Navigating the Menus Studio Color LCD Controller
Navigating the Menus
This section explains how to use the menu system. More
information is contained in subsequent sections in this
chapter.
Summary
• Press the key to enter and exit the menu system.
If you’re in the menu system, pressing the key
takes you completely out of the menu system, no matter
where you are, saving the options you selected.
• Press the Cursor and arrow keys to move up
and down through the menu system one level at a time.
• Use the Cursor and arrow keys to move
between menu options.
• Typically, you use the Construct and arrow
keys to change parameter values; a message appears in
the LCD display telling you if another key is required.
• You also use the Construct and arrow keys
to scroll through pages on multi-page screens.
Getting Started
Upon powering up the controller, after its power-on self-test
successfully completes, the LCD display appears as shown
below:
Press the key to access the menu system. The LCD
display then appears as shown below. This is referred to as
construct
7
#88 #+ -*#+
cursor
