Studio Color LCD Controller

Programming Guided Tour

4-7

4

Manually Playing Back Pages 1 Through 4

1.

Use the Page

and

arrow keys to select page 1, as

shown below:

2.

The fixture(s) programmed for page 1 should now display the
color and position you selected for them.

3.

Press the Page

arrow key to select page 2. The

fixture(s) programmed for page 2 should now display the
color and position you selected for them. Do the same for
pages 3 and 4.

Review

You have now created and manually played back a simple
four-page program. The next sections show you how to
create a loop out of those four pages and then how to record
that loop or any of the pages in the loop as a preset.

Creating a Loop

A loop is a sequence of consecutive pages that continually
plays back until you stop it.

Normally, you create a loop by bracketing the pages on either
side of the loop by un-initialized pages; however, since the
first page in this sample loop is page 1, only one un-
initialized page is required.

1.

Use the Page

and

arrow keys to select memory

1, page 5.

2.

Press the
