3-10 Using the Construct Keys Studio Color LCD Controller
Selecting a particular color construct shows you the
complementary color for that construct. For example, after
selecting the Red construct, the LCD display appears as
shown below (
means 100%):
The second line of the display,
!"#$%%
,
indicates the following:
• RED: the color construct you selected (the primary
color).
• (-CYAN): Red’s complementary color (cyan).
• 255 FF%: the current intensity setting for red (255 =
100% red, or fully saturated with red).
means 100%.
Table 3-1 shows how to derive the three primary colors (red,
green and blue) and their complementary colors (cyan,
magenta and yellow) from the color constructs.
Table 3-1. Primary and Complementary Colors
Color Red setting
Green
setting
Blue setting
Red 255 0 0
Green 0 255 0
Blue 0 0 255
Cyan 0 255 255
Magenta 255 0 255
Yellow 255 255 0
No color
(white) 255 255 255
&'()*))+,
!"#$%%-#'
