B-2 Construct Parameters Studio Color LCD Controller
Color 1—6 (color wheel
position)
forward spin speed 1
(slowest) thru 16 (fastest)
cycle speed 1 (slowest)
thru 16 (fastest)
reverse spin speed 1
(slowest) thru 16 (fastest)
random speed 1
(slowest) thru 16 (fastest)
continuous
1 (open)
Lens 2 (frost) 0 (open)
1—100 (39%):
frost
101 (39%)—220 (86%):
beam shaping
221 (86%)—255 (FF%):
less beam shaping to
open
0
Mode normal color mixing
double color mixing normal
Position Joystick
Preset 1—99 Joystick
Delay 0.0—99.0
Hold for manual advance 0.0
Table B-1. Construct Parameters and Values
Construct Value Range Default
