DIAGnostic:CALibration:OUTPut[:MODE]?
DIAGnostic:CALibration:OUTPut[:MODE]? queries the voltage calibration path
for the module.
Parameters Returns: string.
Comments •
The returned string will be one of CALB or CHAN .
DIAGnostic:CONFigure?
DIAGnostic:CONFigure? returns six 16-bit words indicating the present settings of
the module.
Parameters Returns: six unsigned 16-bit integers (uint16).
Comments •
This query returns six 16-bit words with the following meanings:
Integer
Returned Meaning
1st Expansion Board ID in the form: 0 = present, 7 = none
(expansion board contains channels 9–16).
2nd Terminal Module ID in the form:
0 = screw type, 7 = none or other.
3rd Isolated/Non-Isolated Channel Status
A bit set to 0 indicates an isolated channel.
A bit set to 1 indicates a non-isolated channel or no plug-on module
installed (DO NOT operate the module without a plug-on module).
Bits 0–15 correspond to channels 1–16, respectively*.
4th Channel Mode
A bit set to 0 indicates a current output channel.
A bit set to 1 indicates a voltage output channel.
Bits 0–15 correspond to channels 1–16, respectively*.
5th Channel Output State
A bit set to 0 indicates the channel output relay is closed.
A bit set to 1 indicates the channel output relay is open.
Bits 0–15 correspond to channels 1–16, respectively*.
6th Channel Mode Programmable State (P/J Jumper)
A bit set to 0 indicates a channel is not programmable.
A bit set to 1 indicates a channel is programmable.
Bits 0–15 correspond to channels 1–16, respectively*.
* For 8 channel configurations, the upper 8 bits of integers 3, 4, 5, and 6 are set to 1’s.
DIAGnostic
Chapter 3 HP E1418A SCPI Command Reference 77
