146
Menu List
Menu item Value (bold text: default value) Explanation
GPI 1–8
Macro Execute Macro 1–100 Executes a macro (a series of recorded operations).
Sequencer
Mode On/Off, Next, Previous,
Auto Sequence
When the sequencer function is on, this works the same as
when you press the button selected in “VALUE”.
GPO (One Shot) GPO 1–16 Outputs a control signal for 0.5 seconds.
GPO (Alternate) GPO 1–16
The control signal output is switched on/off each time a
control signal is input.
23: Network
Menu item Value (bold text: default value) Explanation
Priority LAN , Tethering
Sets whether to prioritize the LAN connection or your smartphone tethering when
streaming.
LAN Setup Enter Accesses the LAN settings.
Configure
Selects how settings are made for the IP address, subnet mask, and default gateway.
Manual
This is to be configured manually.
Using DHCP
The IP address and other information needed for connecting to the network is obtained
automatically from the DHCP server of the LAN.
IP Address (*15) –––.–––.–––.––– Specifies the IP address as appropriate for the network to which the unit is connected.
Subnet Mask (*15) –––.–––.–––.––– Specifies the subnet mask as appropriate for the network to which the unit is connected.
Default Gateway (*15) –––.–––.–––.––– Specifies the default gateway as appropriate for the network to which the unit is connected.
DNS Server (*15) –––.–––.–––.–––
Specifies the DNS server address as appropriate for the network to which the unit is
connected.
Start Tethering
Stop Tethering
Exec Starts/stops tethering with your smartphone.
Network Information
Enter Displays the Network Information screen.
Displays the following information.
Item Explanation
Link Status Connection status
IP Address IP address
Subnet Mask Subnet mask.
Default Gateway Default gateway
DNS Server DNS server
2D Code for Smart Tally Enter
QR code for accessing the Smart Tally settings screen (Web)
* Note that the QR code is not shown if the VR-120HD is disconnected from the network.
Network Password Enter
Displays the Network Password screen.
Set the necessary password for network connection, using four characters.
Show password
Password not set
Password set
* Input the password that’s set here when connecting a computer or other device on the
same network to access the VR-120HD.
MAC Address ––:––:––:––:––:–– Displays the MAC address.
(*15) This can be set if “Configure” is “Manual”.
