User’s Manual of WNAP-1110
-25-
4.2 Starting Setup in Web UI
It is easy to configure and manage the WNAP-1110 with web browser.
Step 1. To access the configuration utility, open a web-browser and enter the default IP address
http://192.168.1.253 in the address field of the browser.
Figure 4-5 Login the AP
After a moment, a login window will appear. Enter admin for the User Name and Password, both in lower case
letters. Then click the OK button or press the Enter key.
Figure 4-6 Login Window
Default User Name: admin
Default Password: admin
Default SSID: WNAP-1110
Default Wireless Password: PIN code (refer to the label on the bottom of the WNAP-1110.)
If the above screen does not pop up, it may mean that your web-browser has been set to
a proxy. Go to Tools menu>Internet Options>Connections>LAN Settings, in the screen
that appears, cancel the Using Proxy checkbox, and click OK to finish it.
Step 2. After successfully login, you can click the Quick Setup to quickly configure your AP.
