S UMMIT S WITCH I NSTALLATION AND U SER G UIDE 4-9
P ORT -M IRRORING
P ORT -M IRRORING C OMMANDS
Port-mirroring commands are described in Table 4-7 .
P ORT -M IRRORING E XAMPLE
The following example selects port 3 as the mirror port, and sends all traffic coming
into or out of the switch on port 1 to the mirror port:
enable mirroring port 3
config mirroring add port 1
The following example sends all traffic coming into or out of the switch on port 1 and
the VLAN default to the mirror port:
config mirroring add port 1 vlan default
Table 4-7: Port-Mirroring Configuration Commands
Command Description
enable mirroring port Dedicates a port on the switch to be the mirror port.
config mirroring add [mac
| vlan | port | vlan
port ] Adds a single mirroring filter definition. Up to eight
mirroring definitions can be added. You can mirror
traffic from a MAC address, a VLAN, a physical
port, or a specific VLAN/port combination.
config mirroring delete [mac
| vlan | port
| vlan port | all} Deletes a particular mirroring filter definition, or all
mirroring filter definitions.
disable mirroring Disables port-mirroring.
show mirroring Displays the port-mirroring configuration.
