5-17
D
ISPLAYING
VLAN S
ETTINGS
D
ISPLAYING
VLAN S
ETTINGS
To display VLAN settings, use the following command:
show vlan {
Sample output from this command is as follows:
show vlan all
VLAN Interface [1-fde] with name “net142” created by user
Tagging:
Untagged (Internal tag 4095)
IP:
Not configured
STPD:
Domain “s0” is running spanning tree protocol.
Protocol
AppleTalk = SNAP:809b SNAP:80f3
QoS Profile:
QP1
Ports:
4.
(Number of active port=4)
Untag:
1
2
3
10
LAN Interface [2-fdd] with name “net123” created by user
Tagging:
802.1Q Tag 1054
IP:
123.45.67.1/255.0.0.0
STPD:
Domain “s0” is running spanning tree protocol.
Protocol
Match all unfiltered protocols.
QoS Profile:
QP1
Ports:
18.
(Number of active port=6)
Untag:
1
2
3
4
5
8
9 10
Tagged:
6
7 11 12 13 14 15 16 17 18
The
show
command displays summary information about each VLAN, and includes
the following:
•
Name
•
VLANid
•
How the VLAN was created (manually or by GVRP)
•
IP address
•
STPD information
•
Protocol information
•
QOS profile information
•
Ports assigned
