10-10 S UMMIT S WITCH I NSTALLATION AND U SER G UIDE
R OUTING P ROTOCOLS
RIP C ONFIGURATION E XAMPLE
Figure 10-4 illustrates a switch that has three VLANs defined as follows:
• Finance
— Protocol-sensitive VLAN using the IP protocol
— Ports 1 and 3 have been assigned
— IP address 192.207.35.1
• Personnel
— Protocol-sensitive VLAN using the IP protocol
— Ports 2 and 4 have been assigned
— IP address 192.207.36.1
• MyCompany
— Port-based VLAN
— All ports have been assigned
config rip updatetime {} Changes the periodic RIP update timer. The
timer granularity is 10 seconds. The default
setting is 30 seconds.
Table 10-1: RIP Configuration Commands (continued)
Command Description
