Software options
The iTNC 530 features various software options that can be enabled
by you or your machine tool builder. Each option is to be enabled
separately and contains the following respective functions:
Software option 1
Cylinder surface interpolation (Cycles 27, 28, 29 and 39)
Feed rate in mm/min for rotary axes: M116
Tilting the machining plane (Cycle 19, PLANE function and 3-D ROT
soft key in the Manual Operation mode)
Circle in 3 axes with tilted working plane
Software option 2
Block processing time 0.5 ms instead of 3.6 ms
5-axis interpolation
Spline interpolation
3-D machining:
„ M114: Automatic compensation of machine geometry when
working with swivel axes
„ M128: Maintaining the position of the tool tip when positioning
with swivel axes (TCPM)
„ FUNCTION TCPM: Maintaining the position of the tool tip when
positioning with swivel axes (TCPM) in selectable modes
„ M144: Compensating the machine’s kinematics configuration for
ACTUAL/NOMINAL positions at end of block
„ Additional parameters for finishing/roughing and tolerance for
rotary axes
in Cycle 32 (G62)
„ LN blocks (3-D compensation)
DCM Collision software option Description
Function that monitors areas defined by the
machine manufacturer to prevent collisions. Page 365
DXF Converter software option Description
Extract contours and machining positions from
DXF files (R12 format). Page 240
