HEIDENHAIN iTNC 530 577
16.4 Pr
ogr
am Run
There are two ways to run a tool usage test for a pallet file:
„ The highlight is on a pallet entry in the pallet file:
The TNC runs the tool usage test for the entire pallet.
„ The highlight is on a program entry in the pallet file:
The TNC runs the tool usage test for the selected program.
TIME Tool-usage time in seconds (feed time)
WTIME Tool-usage time in seconds (total usage time
between tool changes)
RAD Tool radius R + Oversize of tool radius DR
from the tool table. The unit is 0.1 µm.
BLOCK Block number in which the TOOL CALL block
was programmed
PATH „ TOKEN = TOOL: Path name of the active main
program or subprogram
„ TOKEN = STOTAL: Path name of the
subprogram
T Tool number with tool index
Column Meaning
